Powertech manufactures high-accuracy Current Transformers (CTs) designed for metering
and protection in medium voltage applications. Available in both resin cast and oil cooled variants,
these CTs are precision-engineered for indoor and outdoor installations.
Advanced Pressure Gelation (APG) technique ensures uniform insulation and high mechanical strength.
Ideal for outdoor and hot-climate installations, offering long-term reliability in harsh conditions.
Small form factor fits into panels and switchboards without compromising functionality.
Available with brackets and customizable terminals for flexible installation needs.
Supports both revenue metering and system protection with precision-rated cores.
Robust insulation and casing options make it adaptable to varied site environments.
| Specification | Details |
|---|---|
| Voltage Class | 11kV / 22kV / 33kV |
| CT Ratio | 5A to 1500A (as per client requirement) |
| Secondary Current | 1A / 5A |
| Accuracy Class | 0.2s, 0.5, 1.0 (Metering); 5P10, 10P10, PS (Protection) |
| Burden | 5VA to 30VA |
| Insulation Type | Resin Cast / Oil Cooled |
| Frequency | 50 Hz |
| Applicable Standards | IS 2705, IEC 61869-2 |
Installed in low and medium voltage switchboards for accurate current sensing and load management.
Used in utility and industrial metering setups for billing and monitoring.
Helps track current usage and trip circuits in large power distribution systems.
Supports protection relays and SCADA systems in smart grids and local substations.
